Power vent design for installation versatility
- Modular blower, with 120V, 60Hz electrical system (5 amps or less), 6-foot cord with standard 3-prong connector - Combined horizontal and vertical vent runs terminating through outside wall, using ULC S636 PVC, CPVC or polypropylene pipe as follows: - 2 ? pipe allows vent runs up to 25 equivalent feet - 3 ? pipe allows vent runs up to 65 equivalent feet - 4 ? pipe allows vent runs up to 120 equivalent feet - Supplied with PVC pipe and elbows to connect heat exchanger outlet to blower, including condensate elbow and drain, and ULC S636 PVC Vent Attenuation Assembly (VAA)
Side-mounted taps for recirculating systems
- Hot and cold "side taps" allow the Envirosense Power Vent to be used for "combination" systems for water heating plus space heating, radiant floor heating or other applicationsrequiring a recirculating hot water loop - Plugs for recirculating taps are shipped with water heater
Intelli-vent gas control with silicon nitride hot surface igniter
- Premium-grade hot surface igniter eliminates standing pilot - Electronic circuitry provides superior system diagnostic capabilities plus extremely precise temperature contro
Commercial-grade glass lining with two magnesium anode rods
- Superior protection against tank corrosion - Glass lining protects all "water side" tank surfaces plus inside of internal heat exchanger exposed to condensate
Diffuser dip tube
- Helps reduce lime and sediment buildup, maximize hot water output - Cross-link polymer withstands long-term exposure to temperatures up to 400F
Six-year limited parts and tank warranty
- Consult written warranty shipped with water heater or contact - GSW for complete warranty information
