Sealed combustion with woven fibre premix burner
Metal fibre burner is designed for clean combustion in high-intensity blue flame mode. Manufactured of refractory steel that resists corrosion. Excellent resistance to thermal and mechanical shock, even at extreme temperatures. Uniform combustion provides excellent heat transfer.
Whisper quiet operation
Ultra quiet blower and burner minimize noise. Requires 120 volt 60Hz power supply. Draws less than 5 Amps.
Power/direct vent using 2" or 3" plastic pipe
Direct vents up to 120' using ULC S636 PVC or CPVC pipe either Thru-the-Wall or Thru-the- Roof. Optional concentric vent kit available for use Thru-the-Roof or Wall.
Plug and play technology
No special adjustments are required at initial start up. Connect air inlet, exhaust outlet, water, electricity, and gas, set the temperature and the system functions properly.
Self diagnostic control system
Three external LED lights indicate operational status of water heater. Microprocessor monitors nine critical functions. An LED troubleshooting light, visible through view port,signals heater operation status.
Full serviceability from the front
Removal of two front-located access panels exposes all serviceable components. Modular components are easily removed.
Energy star qualified
PR100 34 2NV model meets ENERGY STAR requirements
Other features
- Thermister Temperature Sensor - 24-Volt Thermostat Control - Hot Surface Ignition - Full Flow Brass Drain Valve - Zero Clearance to Combustibles - Factory Installed T&P Valve - Factory Provided Condensate Trap - Multiple 1" Brass Tank Connections
